Productdetails:
|
| application: | Other, Automotive Industry, Biofuel Industry, Commercial Buildings, Developing World Water Solutions, District Energy, Drinking Water Treatment, Family Homes, Food And Beverage Industry, Hvac OEM, Industrial Boilers, Industrial Utilities, Irrigation and Ag | warranty: | 1 year |
|---|---|---|---|
| customized support: | OEM, ODM | horsepower: | None |
| motor: | None | power source: | Pneumatic |
| structure: | Diaphragm Pump | voltage: | None |
| Material: | PP | Name: | AODD Pump |
| Color: | white | Connection Type: | Flange |
| Diaphragm: | VT | Brand: | RV |
| Packing: | carton | Max pressure: | 120psi(0.84Mpa,8.4bar) |
| Pump body: | PP | Max Flow: | 150gpm(570lpm) |
| Power: | None | ||
| Markeren: | 2 inch AODD pomp voor afvalwater,pneumatische membraanpomp met VT membraan,PP flens drinkwaterpomp |
||
Maximale Werkdruk | 120 psi (0,84 MPa, 8,4 bar) |
Maximale Doorstromingssnelheid | 150 gpm (570 L/M) |
Maximale Zuiger-Slagsnelheid | 145 cpm |
Maximale Zuighoogte (Droogzuigen) | 5m |
Maximaal Toegestaan Korrel | 0,2 inch (6 mm) |
Maximaal Luchtverbruik | 140 scfm (70 L/S) |
Luchtinlaat Maat | 1/2 inch |
Luchtuitlaat Maat | 3/4 inch |
Vloeistofinlaat Maat | 2 inch |
Vloeistofuitlaat Maat | 2 inch |
Gewicht | PP pomp: 31 KGS |
